ENGINE

Cylinder Head Measuring M/C

Crankshaft Measuring M/C

Camshaft Measuring M/C

Vessel Engine Valve Straightening M/C

Cylinder Block Bore/ Crank Hole Measuring & Marking Machine

Measurement Points/Items: I.D of bore (Air/ Electric micrometer); I.D of crank journal hole (Air/ Electric micrometer); Marking of rank (Laser marker/ Engraving marker)

Cylinder Head Cam/ Guide/ Seat/ Reamer/ Lifter Hole Measuring Machine

Measurement Points/Items: I.D. of cam journal hole (Air/ Electric micrometer); I.D of guide hole, seat hole, reamer hole, lifter hole (Air micrometer); I.D. of injection hole (Air micrometer); Knock hole etc. (Air micrometer)

Crankshaft Measuring & Marking Machine

Measurement Points/Items: Journal O.D., runout (Electric micrometer); O.D, 1/2 stroke of pin (Electric micrometer); O.D of flange, front shaft (Electric micrometer); O.D. of counter weight (Electric micrometer); Thrust with, length (Electric micrometer); Marking of rank (Laser marker/ Engraving marker)

Crankshaft Straightening Machine

Rectification Points/Items: Runout of journals in both end journal datum (Electric micrometer); Runout of journals in both center hole datum (Electric micrometer)

Camshaft Measuring Machine

Measurement Points/Items: O.D, runout of journal (Electric micrometer); Diameter of cam base circle, runout, major axis, minor axis
(Electric micrometer); Cam profile error, phase angle (Electric micrometer); Thrust width, length (Electric micrometer)

Camshaft Straightening Machine

Rectification Points/Items: Runout of journals in both end journal datum (Electric micrometer); Runout of journals in both center hole datum (Electric micrometer)

Connecting Rod I.D Measuring & Weight Rank Sorting Machine

Measurement Points/Items: I.D, roundness, cylindericity of big end (Air/ Electric micrometer); I.D, roundness, cylindericity of small end (Air/ Electric micrometer); Torsion/ bend of small end I.D. against the big end I.D.
(Air/ Electric micrometer); Weight (big end, small end, total); Marking of I.D and weight rank (Laser marker/ Engraving marker)

Engine Valve Measuring Machine

Measurement Points/Items: Runout of shaft (Electric micrometer); Runout of valve head (Electric micrometer)

Valve Lifter Sorting Machine

Measurement Points/Items: Valve height in cylinder head (Electric micrometer); Base circle height for camshaft (Electric micrometer); Sorting of valve lifter with data calculation
